BAILUN Benchtop Dual-Tank Bioreactor System for Parallel Cell Culture Fermentation 0.25L-10L
- Model
- BL-DTB-0.25-10L
Item specifics
- Configuration
- Dual-tank (duplex), parallel or independent
- Working Volume
- 0.25 L to 10 L per vessel
- Material
- Stainless steel / borosilicate glass vessel
- Control
- Color touchscreen HMI, pH/DO/temp/agitation
Review
Description
The BAILUN benchtop dual-tank bioreactor is a compact, modular fermentation system designed to deliver maximum flexibility in cell culture and microbial processes. Two independently controlled vessels operate in parallel or separately, enabling side-by-side comparison of strains, media, and feeding strategies while shortening development timelines. Integrated monitoring and control of pH, dissolved oxygen (DO), temperature, and agitation, combined with peristaltic dosing pumps and a color touchscreen HMI, give operators precise and reproducible conditions for every run. Working volumes from 0.25 L to 10 L make the system equally suited to early screening and pilot-scale optimization. Two independently controlled vessels run side-by-side for direct comparison of strains, media, and process conditions in a single experiment. Stirring from 50 to 2000 rpm with ±1 rpm accuracy delivers efficient, reproducible mixing across microbial and cell culture applications. Temperature stability within ±0.1 °C keeps culture conditions consistent and supports reliable scale-up decisions. Closed-loop monitoring and control of pH, dissolved oxygen, temperature, and agitation in each vessel for stable, repeatable runs. Four peristaltic pumps per vessel for accurate addition of acid, base, antifoam, and feed media without cross-contamination. Working volume range from 0.25 L to 10 L per vessel supports early-stage screening through pilot-scale process optimization. Modular architecture adapts the platform to bacterial, yeast, fungal, plant cell, and mammalian cell culture workflows. Intuitive color HMI with full data logging and traceability streamlines operation and supports traceable bioprocess workflows. Run parallel comparisons of strains, carbon sources, and feed strategies to identify optimal conditions faster. Reliable cultivation of bacteria, yeasts, fungi, and cell cultures for research and small-scale production. Enzymes, probiotics, starter cultures, and functional ingredients for food and beverage R&D. Production of metabolites, organic acids, bioethanol, and other value-added compounds. Development of active ingredients, proteins, peptides, and bioactive compounds under controlled conditions. Kinetics studies, kLa characterization, and process scale-up experiments in university and institute labs. Yes. Each vessel has its own control loop for pH, DO, temperature, and agitation, so the two tanks can run independent recipes, different strains, or parallel comparisons in the same experiment. The dual-tank system supports working volumes from 0.25 L to 10 L per vessel, making it suitable for early-stage screening as well as pilot-scale process optimization. Yes. The platform supports mammalian, insect, plant, and microbial cell culture workflows. The low-shear impeller options and precise DO control make it well suited for sensitive cell lines. All process parameters are continuously logged through the color touchscreen HMI, with export options for downstream analysis and traceability documentation. Vessels, piping, and seals are designed for easy disassembly and sterilization. The system is compatible with standard autoclave and clean-in-place workflows used in modern biotech labs. Talk to a BAILUN bioreactor specialist about vessel sizes, sensor packages, and integration with upstream and downstream equipment.
Two Vessels. One Platform. Total Flexibility.
Parallel fermentation in a compact benchtop footprint
Engineered for Reproducible Bioprocess R&D
Dual-Tank Parallel Operation
Wide Agitation Range
Precise Temperature Control
Integrated pH, DO, and Agitation Control
Peristaltic Dosing System
Flexible Working Volumes
Modular and Configurable
Color Touchscreen with Data Logging
Built for Today’s Biotech R&D
Strain & Media Screening
Biomass Production
Food-Grade Fermentation
Industrial Biotechnology
Pharma & Cosmetic R&D
Academic Research
Engineered to Spec
Configuration Dual-tank, parallel or independent operation Working Volume 0.25 L to 10 L per vessel Agitation Range 50 to 2000 rpm, accuracy ±1 rpm Temperature Control Accuracy ±0.1 °C Monitoring pH, dissolved oxygen (DO), temperature, agitation Dosing Pumps Peristaltic pumps for acid, base, antifoam, and feed Control Interface Color touchscreen HMI with data logging and traceability Applications Microbial, yeast, fungal, plant cell, and mammalian cell culture Footprint Compact benchtop design, suitable for pilot labs
Frequently Asked Questions
Can the two vessels run different processes at the same time?
What working volumes are supported?
Is the system suitable for mammalian cell culture?
Does the system support data logging and traceability?
How is the platform maintained and cleaned?
Configure the Right Dual-Tank System for Your Process
